696028 - Stud Mount Diode, 1/4" Stud 70 Amp, 400 PRV Positive Base (Cathode to Case)
Heavy Duty 1/4" Stud Mount Diode
Rated at 70 Amp, 400 Peak Reverse Voltage
Used in Positive Output Chargers (Cathode to Case)
Used to repair rectifiers in various positive output battery chargers - those chargers with the positive DC lead/clamp assembly connected to the rectifier heat sink plate.
Available each, or value packs of 2 and 6.
Features
• 1/4" Mounting Stud
• Solderable Stem Eyelet
• Positive Base / Cathode to Case
Heavy Duty 1/4" Stud Mount Diode
Rated at 70 Amp, 400 Peak Reverse Voltage
Used in Positive Output Chargers (Cathode to Case)
Used to repair rectifiers in various positive output battery chargers - those chargers with the positive DC lead/clamp assembly connected to the rectifier heat sink plate.
Available each, or value packs of 2 and 6.
Features
• 1/4" Mounting Stud
• Solderable Stem Eyelet
• Positive Base / Cathode to Case
Original: $6.45
-65%$6.45
$2.26Description
Heavy Duty 1/4" Stud Mount Diode
Rated at 70 Amp, 400 Peak Reverse Voltage
Used in Positive Output Chargers (Cathode to Case)
Used to repair rectifiers in various positive output battery chargers - those chargers with the positive DC lead/clamp assembly connected to the rectifier heat sink plate.
Available each, or value packs of 2 and 6.
Features
• 1/4" Mounting Stud
• Solderable Stem Eyelet
• Positive Base / Cathode to Case
